Rongke Wall-mounted
Brief description
12kWh wall-mounted lithium battery, the best choice for both residential and commercial energy storage! Lithium iron phosphate is safer, wall-mounted design saves space and is easy to install, suitable for multiple scenarios, flexible expansion, economical and efficient.
Detailed Description
16S2P Lithium Iron Phosphate Wall-mounted Battery | Exclusive for Overseas Household/Small Commercial Use
16S2P lithium iron phosphate module + intelligent BMS, wall-mounted to save space, installable by one person, supporting parallel connection for expansion; wide temperature range and silent operation, full coverage of international certifications, directly connected to photovoltaic/power supply systems.
Product Features
1.Safety: Class A lithium iron phosphate battery cells + multiple protections, IP21+ international certification
2.Intelligence: BMS real-time monitoring, RS485 linkage, efficiency ≥95%
3.Flexibility: Easy wall-mounted installation, support for parallel expansion, wide temperature range of -20~55°C
4.Durability: ≥6000 cycles, 10-15 years of service life, silent heat dissipation
| Product Name | Rongke Wall-mounted | ||
| Capacity (Ah) | 200Ah | Design life | ≥6000 cycles，10-15year |
| Nominal energy (KWh) | 10KWH | Operating temperature (°C) | Charging 0~45；Discharg- 20~55 |
| Module Specification | 16S2P | Efficiency (%) | ≥95% |
| Nominal voltage (V) | 51.2V | Product Size: length / width / height (mm) | 1100×520×195 |
| Operating voltage (A) | Charge cut-off 57.6V Discharge cut-off 46.4V |
Product Weight (KG) | ≈100KG |
| Maximum discharge current (A) | 100A | Warranty Period (years) | 5~10 |
| Continuous charging Current (A) | 75A | Environmental humidity Range (%) | 5% ~ 95% |
| Battery technology | Lithium iron phosphate Grade A battery cells |
Cooling method | Intelligent heat dissipation |
| Communication BMS Method | RS485 | Installation | Wall-mounted (supports parallel connection) |
| Protection Safety | Multiple protection + fireproof insulation IP21 protection |
Certificats | UN38.3、CE、RoHS |
